FREIGHT ELEVATORS |
|
|
|
|
|
STANDARD TECHNICAL CHARACTERISTICS |
||||||
| Capacity | Car | Clear entrance | Shaft | Pit | Overhead | Speed |
| 1500kg | 1700x2000 | 1400 | 2300x2572 | 1200 | 3600 | 0,2 m/s |
| 2000kg | 2000x2100 | 1400 | 2300x3072 | 1200 | 3600 | 0,2 m/s |
| 2500kg | 2000x2500 | 1400 | 2600x3072 | 1200 | 3600 | 0,2 m/s |
| 3000kg | 2300x2500 | 1400-1800 | 2900x3072 | 1200 | 3600 | 0,2 m/s |
| 3500kg | 2500x2600 | 1400-1800 | 2900x3472 | 1200 | 3600 | 0,2 m/s |
| 4000kg | 2600x2800 | 1400-1800 | 2900x3772 | 1200 | 3600 | 0,2 m/s |
|
|
